- 72 -
Maximum sound power level (Lw) complies with 2000/14/EC 90 dB(A)
Capacity of standard fuel tank 109 l
Single step load capability 100%
4.9 kW
Application data Mode of operation PRP
Site land use
Operation single
Start-up and control mode manual/auto
Start-up time unspecified
Mobility/Config. acc. to ISO 8528-1:1993 transportable
(optional) mobile
Mounting fully resilient
Climatic exposure open air
Status of neutral (TT or TN) earthed
Design Data Engine Standard ISO 3046
ISO 8528-2
Make Kubota
Model D1105-EBG2
Rated net output 8.4 kW
Rating type acc. ISO 3046-7 ICXN
Coolant coolant
Combustion system indirect injection
Aspiration natural aspirated
Number of cylinders 3
Swept volume 1.12 l
Speed governing mechanical
Capacity of oil sump - Initial fill 5.1 l
Capacity of cooling system 3.1 l
Electrical system 12 Vdc
Maximum permissible load factor of PRP during 24h period 100%
00_00_HiLight H4_EN.book Page 72 Monday, April 18, 2016 2:10 PM
