QAS28 Yd(S), QAS28 YdS IT
30
6
3(&,),&$7,216
2)
7+(
237,216
6SHFLILFDWLRQVRIWKHVRFNHWVRSWLRQ
6SHFLILFDWLRQVRIWKHGXDOIUHTXHQF\RSWLRQ
6SHFLILFDWLRQVRIWKHGXDOYROWDJHRSWLRQ
&
219(56,21
/,67
2)
6,
81,76
,172
%
5,7,6+
81,76
A temperature difference of 1°C = a temperature difference of 1.8 °F
QAS28 YdS IT:
Setting of Q2 32 A 32 A
QAS28 YdS IT:
Setting of Q3 16 A 16 A
QAS28 YdS IT:
Setting of Q4 16 A 16 A
Fuses F1, F3 4 A 4 A
QAS28 YdS IT:
Sensitivity of insulation monitoring relay
10 .... 100 k
10 .... 100 k
Unit
Dimensions (LxWxH) 2080 x 951 x 1157 mm 2080 x 951 x 1157 mm
Weight net mass 859 kg 859 kg
Weight wet mass 975 kg 975 kg
QAS28 Yd(S):
Setting of circuit breaker Q2 32 A 32 A
QAS28 Yd(S):
Setting of circuit breaker Q3 16 A 16 A
QAS28 Yd(S):
Setting of circuit breaker Q4 16 A 16 A
QAS28 Yd(S):
Frequency 50/60 Hz 50/60 Hz
QAS28 Yd(S):
Output voltage 230/400 V 220/480 V
QAS28 Yd(S):
Setting of circuit breaker Q1.1 63 A 63 A
QAS28 Yd(S):
Setting of circuit breaker Q1.2 40 A 40 A
1 bar = 14.504 psi 1 m = 3.281 ft
1 g = 0.035 oz 1 mm = 0.039 in
1 kg = 2.205 lb 1 m³/min = 35.315 cfm
1 km/h = 0.621 mile/h 1 mbar = 0.401 in wc
1 kW = 1.341 hp (UK and US) 1 N = 0.225 lbf
1 l = 0.264 US gal 1 Nm = 0.738 lbf.ft
1 l = 0220 lmp gal (UK)
t
°F
=
32 + (1.8 x t
°C
)
1 l = 0.035 cu.ft
t
°C
=
(t
°F
- 32)/1.8
