4.2.4.3 Qc1002™ menu description
Status display (pop-up window)
In case special statuses are entered (e.g. diagnostic
mode), a pop-up window will automatically be
entered for as long as the status is active.
The background screen is not updated when the status
pop-up window is active.
If a special status has elapsed, the active view will be
entered again automatically.
If an Alarm comes up, the Alarm Display is shown.
Controller type and version display
This view shows the controller type and the ASW
version number.
Parameter display
This view shows a number of Parameter settings and
gives access to them.
An overview is given in “Parameter list” on page 35.
Alarm list display
This view shows the number of active alarms and
gives access to them.
An overview is given in “Solving alarms” on page 56.
LOG list display
This view shows the alarm memory and gives access
to it.
An overview is given in “LOG list” on page 38.
To Next Page
