- 35 -
Service timer 1 & Service timer 2 display
This view shows both Service timers. The service
timer indication is shown when service time has run
out. It can be removed by resetting the timers or
acknowledging the Service timer indication.
The service timer indications count and give an alarm
when value is reached.
Resetting the Service Timers can be done through the
Parameter display.
Battery Voltage display
This view shows the Battery voltage and the running
hours.
Voltage - frequency - running hours display
This view shows the voltage, frequency and running
hours.
4.2.4.4 Parameter list
The Parameter Menu's are pre-programmed!
A password will be asked for when an attempt to
change a setting is about to be done (user password =
2003).
Menu's shown on the Parameter list LCD:
– Running hours adjust
This menu is used to adjust the amount of running
hours. The running hours can only be highered,
not lowered.
–Unit Type
– Service Timer 2 reset
– Service Timer 1 reset
These menus are used to reset the service timers.
When a service timer alarm occurs and is
acknowledged, the service timer will be reset
automatically.
Service 1
Service 2
59h
59h
13.2 VBattery
00168.1h
50Hz400V
00168.1h
Unit type 4 for QAX 12-20-24-30-35!
!
