Atlas Copco QAX 20 Dd S2 APP - QAX 24 Technical Specifications

- 78 -
10.3 Technical specifications for QAX 24
10.3.1 Readings on gauges
10.3.2 Settings of switches
10.3.3 Specifications of the engine/alternator/unit
Gauge Reading Unit
Ammeter L1 (P1) Below max. rating A
Voltmeter (P4) Below max. rating V
Switch Function Activates at
Engine oil pressure Shut down 0.5 bar
Engine coolant temperature Shut down 105°C
240 V - 3-phase
Reference conditions 3) Rated frequency 60 Hz
Rated speed 1800 rpm
Generator service duty PRP
Absolute air inlet pressure 100 kPa
Relative air humidity 30%
Air inlet temperature 25°C
Limitations 1) Maximum ambient temperature 50°C
Altitude capability 4000 m
Maximum relative air humidity < 100%
Minimum starting temperature -10°C
Minimum starting temperature aided NA
Performance data 1) 2) 4) Rated active power (PRP) 3-phase 19.8 kW
Rated active power (PRP) 1-phase -
Rated power factor (lagging) 3-phase 0.8
Rated power factor (lagging) 1-phase -
