10.5 Technical specifications for QAX 35
10.5.1 Readings on gauges
10.5.2 Settings of switches
10.5.3 Specifications of the engine/alternator/unit
Gauge Reading Unit
Ammeter L1 (P1) Below max. rating A
Voltmeter (P4) Below max. rating V
Switch Function Activates at
Engine oil pressure Shut down 0.5 bar
Engine coolant temperature Shut down 105°C
240 V - 3-phase
Reference conditions 1) 3) 4) Rated frequency 60 Hz
Rated speed 1800 rpm
Generator service duty PRP
Absolute air inlet pressure 1 bar(a)
Relative air humidity 30%
Air inlet temperature 25°C
Limitations 2) Maximum ambient temperature 50°C
Altitude capability 4000 m
Maximum relative air humidity 85%
Minimum starting temperature -10°C
Performance data 2) 3) 5) Rated active power (PRP) 3-phase 28.4 kW
Rated power factor (lagging) 3-phase 0.8
Rated apparent power (PRP) 3-phase 35.5 kVA
Rated voltage 3-phase, line to line 240 V
Rated current 3-phase 86.1 A
