- 74 -
Rated apparent power (PRP) 3-phase 20 kVA
Rated apparent power (PRP) 1-phase -
Rated voltage 3-phase, line to line 400 V
Rated voltage 1-phase, line to line -
Rated current 3-phase 28.9 A
Rated current 1-phase -
Performance class (acc.ISO 8528-5:1993) G2
Single step load acceptance (0-PRP) 16 kW
100%
Frequency droop < 5%
Fuel consumption at no load (0%) 0.93 kg/h
Fuel consumption at 50% load 2.38 kg/h
Fuel consumption at 75% load 3.13 kg/h
Fuel consumption at full load (100%) 4.00 kg/h
Specific fuel consumption 0.25 kg/kWh
Fuel autonomy at full load 16.3 h
Max. oil consumption at full load 0.014 l/h
Maximum sound power level (LWA) measured according to 2000/14/EC OND
with metal canopy 93 dB(A)
with PE canopy (optional) 90 dB(A)
Capacity of fuel tank 80 l
Single step load capability 16 kW
100%
Application data Mode of operation PRP
Site land use
Operation single
Start-up and control mode manual/automatic (remote)
Start-up time unspecified
Mobility/Config. acc. to ISO 8528-1:1993 transportable/D
(optional) mobile/E
Mounting fully resilient
Climatic exposure open air
Status of neutral (ELR-config) earthed
