- 92 -
Derating factor %
Height
(m)
Temperature
(°C)
0 5 10 15 20 25 30 35 40 45 50
0 100 100 100 100 100 100 100 100 100 90 90
500 100 100 100 100 100 100 100 100 100 90 90
1000 100 100 100 100 100 100 100 95 95 90 80
1500 100 100 100 100 100 100 95 90 90 85 80
2000 1001001009595909085808075
2500 95 95 95 95 90 85 85 80 75 NA NA
3000 95 95 90 90 85 80 80 75 75 NA NA
3500 85 85 85 85 80 80 75 NA NA NA NA
4000 85 85 85 80 80 75 70 NA NA NA NA
