- 101 -

F1-F2 Fuses 4 A

G3 Alternator

N12 Automatic voltage regulator

N13 Earth leakage relay (O)

N14 IT relay (O)

Q1 Circuit breaker

Q2 Circuit breaker 32 A

Q3 Circuit breaker 16 A/30 mA

S2b Emergency stop

(S2a: see engine circuit)

S13 Earth leakage disable switch (O)

T13 Torus earth leakage (O)

X1 Outlet socket 63 A

X2 Outlet socket 32 A

X3 Outlet socket 16 A (1P+N)

X9 Terminal strip

(O) Optional equipment
