- 26 -
Brake cable adjustment
– With the towing eye pulled out in the outmost
position and the hand brake lever in the downward
position (see figure below), loosen the lock nuts
(2). Turn adjusting nuts (3) and brake cable nuts
(4) clockwise until there is no slack in the brake
mechanism.
The equalizer must remain perpendicular to main
brake cable (5).
– Apply the hand brake lever several times and
repeat the adjustment. Tighten the nuts with their
lock nuts (2). Remove the jack and the blocks.
– Road test the generator and brake several times.
Check brake shoe and brake cable adjustment and
if necessary adjust.
