- 76 -
Insulation resistance (IT-config) 10-100 kOhm
Outlet sockets Domestic (1x)
2P + E
16 A 230 V
CEE form (1x)
3P + N + E
16 A 400 V
CEE form (1x)
3P + N + E
32 A 400 V
Unit Dimensions with undercarriage (adj. with breaks) (LxWxH) 3562 x 1410 x 1258 mm
Dimensions with undercarriage (fixed with breaks) (LxWxH) 3160 x 1410 x 1258 mm
Dimensions without undercarriage (LxWxH) 2016 x 1040 x 1019 mm
Weight net mass - Box 737 kg
Weight wet mass - Box 804 kg
Weight net mass - Undercarriage AB 879 kg
Weight wet mass - Undercarriage AB 946 kg
Weight net mass - Undercarriage FB 864 kg
Weight wet mass - Undercarriage FB 931 kg
