- 90 -
Combustion system direct injection
Aspiration turbocharged
Number of cylinders 3 - in line
Swept volume 2.33 l
Speed governing mechanical
Capacity of oil sump - Initial fill 5.5 l
Capacity of cooling system 8 l
Electrical system 12 Vdc
Maximum permissible load factor of PRP during 24h period 80%
Alternator Standard IEC34-1
ISO 8528-5
Make Leroy Somer
Model LSA42.3 VS3
Rated output, class H temp. rise 40 kVA
Rating type (acc. ISO 8528-3) "BR" 125/40°C
Degree of protection (IP index acc. NF EN 60-529) IP 23
Insulation stator class H
Insulation rotor class H
Number of wires 12
Power circuit Circuit-breaker, 3-phase
Number of poles 4
Thermal release It (thermal release is higher at 25°C) 100 A
Magnetic release Im 3..5xIn
Fault current protection
Residual current release IDn 0.03-30 A
Insulation resistance 10 - 100 kOhm
Unit Dimensions with undercarriage (adj. with breaks) (LxWxH) 3562 x 1410 x 1258 mm
Dimensions with undercarriage (fixed with breaks) (LxWxH) 3160 x 1410 x 1258 mm
Dimensions without undercarriage (LxWxH) 2016 x 1040 x 1019 mm
