- 53 -
Cylindrical hub cap shape
Compact bearings
Compact bearings are recognizable by cylindrical hub
cap shape, see Figure.
Compact bearings are maintenance-free due to
permanent lubrication and are designed for high
mileages.
Therefore, there is no grease change or regreasing
necessary.
WHEEL BOLTS CHECK
Wheel bolts tightening
Tighten wheel bolts crosswise using a torque wrench
to the tightening torque in compliance with the table.
Tightening torques of wheel bolts
After the first run, likewise after each
wheel change.
Spanner
width (mm)
Thread Tightening
torque
17 (19) M 12x1.5 80 100 Nm
19 M 14x1.5 110 120 Nm
24 M 18x1.5 270 280 Nm
