Performance data
1)
Design Data
COMPRESSOR
ENGINE
UNIT
Designation XAS 185 KD7
Engine shaft speed, normal and maximum rpm 2700-2800
Engine shaft speed, compressor unloaded rpm 1650-1700
Free air delivery
2)
l/s 87.31
cfm 185
Fuel consumption -at full load gal/hr 2.31
-at unload gal/hr 0.99
Specific fuel consumption gal/ft
3
0.00022
Typical oil content of compressed air mg/m
3
<5
oz/1000 cu.ft < 0.005
Engine oil consumption (maximum) g/hr NA
oz/h NA
Compressed air temperature at outlet valves °C 93.3
°F 200
Noise level
6)
dB(A) 74
Designation All units
Number of compression stages 1
Designation XAS 185 KD7
Make Kubota
Type V2403-M-DI-E3B
Coolant
Ethylene glycol mix w/SCA
package
Number of cylinders 4
Bore
in 3.43
mm 87.12
Stroke
in 4.03
mm 102.36
Swept volume
cu.in 148.50
l2.43
Output at normal shaft speed
5)
hp 49
kW 36.53
- Load factor % 75
Capacity of oil sump
qts 10
gal 2.5
-Refill (max.)
4)
qts 11
gal 2.75
Capacity of cooling system
qts 10
gal 2.5
Designation All units
Capacity of compressor oil system
qts 9
gal 2.25
Net capacity of air receiver
US gal 4.5
l 17.03
Capacity of fuel tanks
US gal 20
l 75.70
Air volume at inlet grating (approx.)
3)
cfm 6340
m
3
/s 2.99
Designation XAS 185 KD7
