Atlas WB11 User Manual

REV. 03 15 / 22
6.4 BALANCING MODE
6.4.1 DYNAMIC MODE
The dynamic mode is used for most passenger and light truck wheels using the most common location
for corrective weights. Clip-on weights are placed on the inner and outer sides of the rim.
On the initial screen press
Fig. 14
Correction of outer side Correction of inner side
6.4.2 STATIC MODE
The static mode is used for motorcycles or narrow wheels when it is not possible to place the
counterweights on both sides of the rim. Clip a single weight on one of sides of the rim or in centre of
wheel according to the diameter of the wheel mounted.
Press to select “Static mode” when the
LED indicator lights up and then press
Fig. 15

Atlas WB11 Specifications

General

Brand	Atlas
Model	WB11
Category	Wheel Balancers
Language	English
