REV. 03 16 / 22
6.4.3 STANDARD ALU MODE
All the ALU modes are dynamic balance. Choose the option that best fits the available locations as
shown in the figure 16.
From the measurement screen, press to select the modes ALU1 ALU2 ALU3
ALU4.
Fig. 16
Balancing of light alloy rims with
application of adhesive weights on the rim
shoulders.
Both weight positions are fixed.
Balancing of light alloy rims with hidden
application of adhesive weights.
Outer weight position is fixed.
Combination application: clip-on weight
inside and hidden adhesive weight on
outside.
Outer weight position is same as ALU2.
Combination application: adhesive weight
outside and clip-on weight inside.
Outer weight position is same as ALU1.
To Next Page
