67
8271D–AVR–05/11
ATmega48A/PA/88A/PA/168A/PA/328/P
Address Labels Code Comments
;
.org 0x1C00
0x1C00 jmp RESET ; Reset handler
0x1C02 jmp EXT_INT0 ; IRQ0 Handler
0x1C04 jmp EXT_INT1 ; IRQ1 Handler
... ... ... ;
0x1C32 jmp SPM_RDY ; Store Program Memory Ready Handler
;
0x1C33 RESET: ldi r16,high(RAMEND); Main program start
0x1C34 out SPH,r16 ; Set Stack Pointer to top of RAM
0x1C35 ldi r16,low(RAMEND)
0x1C36 out SPL,r16
0x1C37 sei ; Enable interrupts
0x1C38 <instr> xxx
12.4 Interrupt Vectors in ATmega328 and ATmega328P
Table 12-6. Reset and Interrupt Vectors in ATmega328 and ATmega328P
VectorNo.
Program
Address
(2)
Source Interrupt Definition
1 0x0000
(1)
RESET
External Pin, Power-on Reset, Brown-out Reset and Watchdog System Reset
2 0x0002 INT0 External Interrupt Request 0
3 0x0004 INT1 External Interrupt Request 1
4 0x0006 PCINT0 Pin Change Interrupt Request 0
5 0x0008 PCINT1 Pin Change Interrupt Request 1
6 0x000A PCINT2 Pin Change Interrupt Request 2
7 0x000C WDT Watchdog Time-out Interrupt
8 0x000E TIMER2 COMPA Timer/Counter2 Compare Match A
9 0x0010 TIMER2 COMPB Timer/Counter2 Compare Match B
10 0x0012 TIMER2 OVF Timer/Counter2 Overflow
11 0x0014 TIMER1 CAPT Timer/Counter1 Capture Event
12 0x0016 TIMER1 COMPA Timer/Counter1 Compare Match A
13 0x0018 TIMER1 COMPB Timer/Coutner1 Compare Match B
14 0x001A TIMER1 OVF Timer/Counter1 Overflow
15 0x001C TIMER0 COMPA Timer/Counter0 Compare Match A
16 0x001E TIMER0 COMPB Timer/Counter0 Compare Match B
17 0x0020 TIMER0 OVF Timer/Counter0 Overflow
18 0x0022 SPI, STC SPI Serial Transfer Complete
19 0x0024 USART, RX USART Rx Complete
20 0x0026 USART, UDRE USART, Data Register Empty
