Figure 37. Idle Supply Current vs. V
CC
Figure 38. Power-down Supply Current vs. V
CC
0
1
1
2
2
3
2 2.5 3 3.5 4 4.5 5 5.5 6
T = 25˚C
A
T = 85˚C
A
IDLE SUPPLY CURRENT vs. V
cc
V
CC
(V)
FREQUENCY = 4 MHz
I (mA)
CC
0
1
2
3
4
5
6
7
8
9
1.5 2 2.5 3 3.5 4 4.5 5 5.5 6
T = 85˚C
A
T = 25˚C
A
POWER-DOWN SUPPLY CURRENT vs. V
cc
V
CC
(V)
WATCHDOG TIMER DISABLED
I (µA)
CC
