Atomic BZ3 - Step 11.1 - Front Upper Arms

BZ3 Instruction manual
13
13
Note:
1.5*2.5*0.35 white washer is used to adjust the Front Caster Angle (upper arm inclination).
More caster angle will generate more steering but degrease in stability. We recommend you
try different degree to find the best position for you.
Every 0.35mm move = 1-degree change of caster angle.
Step 11.1 – Front Upper Arms
M2*2.5 set screw
M2*2.5 set screw
