BZ3 Instruction manual
19
19
O-ring (Rubber)
Steering Collar
M2 x 10
M2x4
M2x4
M2x4
M2x4
Pay attention to the
direction.
Step 16 – Spur Gear
Step 17 – Upper Deck
