Atomos SHINOBI Quick Start Guide

2 Shinobi - Quick Start Guide
Contents
Thank you for purchasing the Atomos Shinobi, utilising
professional HDMI connectivity to monitor professional
4Kp30. The class leading AtomHDR monitor lets you visualize
10.5+ stops of dynamic range, with 1000nit brightness
for daylight viewing and 10-bit processing for smooth
gradations. With so many Monitor features, please take the
time to read through this Quick Start Guide and register your
product for free updates.
DOWNLOAD THE FULL
SHINOBI USER MANUAL
www.atomos.com/support
Introduction
Introduction ........................ 2
Checklist .......................... 3
You will also need .................. 3
AtomX Accessories ................ 3
Getting started ..................... 4
Connect and Power-up ............. 4
Physical features ................... 5
Touchscreen/User Interface ........ 8
Monitor assist tools ................ 9
Warranty & Conditions ............. 10

Atomos SHINOBI Specifications

General

Aspect ratio	16:9
LED backlight	-
Pixel density	427 ppi
Display diagonal	5.2 \
Display technology	IPS
Input voltage	6.2 - 16.8 V
Power supply type	Battery
Power consumption (max)	7 W
Power consumption (typical)	4 W
HDMI version	1.4
Headphone out	Yes
Product color	Black
Housing material	Polycarbonate (PC)
Connecting thread	1/4 \
Compatible memory cards	SD
Cables included	HDMI
Audio sampling rate	48 kHz
Supported video modes	720p, 2160p
Resolution at capture speed	1280x720@50fps, 1920x1080@23.98fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@59.94fps, 3840x2160@23.98fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@29.97fps, 4096x2160@23.98fps, 4096x2160@24fps, 4096x2160@25fps

Weight and Dimensions

Depth	31.5 mm
Width	151 mm
Height	91.5 mm
Weight	196 g
