Atomos SHINOBI Quick Start Guide

4 Shinobi - Quick Start Guide
Connect and power-up
Battery / Battery Eliminator
Shinobi has a single battery slot. To connect a compatible
battery, place the battery in front of the retaining lug, align
with the connectors and slide the battery into the lock
position.
To connect the supplied Battery Eliminator, follow the same
procedure and lock battery into position.
Touching the Battery icon in the top right of your screen will
allow you to accurately see remaining battery life. Refer to
the User Manual for more information.
Power
You can power the device using the supplied AC power
supply, but if you plan to use a battery we recommend you
fully charge before use.
Choosing the right battery for your application
Battery time
(Based on 7.4V)
Standby mode Monitor mode
2600mAh - 3hrs 2600mAh - 1.5hrs
5200mAh - 6hrs 5200mAh - 3hrs
7800mAh - 12hrs 7800mAh - 6hrs
We recommend using Atomos NP-F series batteries.
Getting started

Atomos SHINOBI Specifications

General

Aspect ratio	16:9
LED backlight	-
Pixel density	427 ppi
Display diagonal	5.2 \
Display technology	IPS
Input voltage	6.2 - 16.8 V
Power supply type	Battery
Power consumption (max)	7 W
Power consumption (typical)	4 W
HDMI version	1.4
Headphone out	Yes
Product color	Black
Housing material	Polycarbonate (PC)
Connecting thread	1/4 \
Compatible memory cards	SD
Cables included	HDMI
Audio sampling rate	48 kHz
Supported video modes	720p, 2160p
Resolution at capture speed	1280x720@50fps, 1920x1080@23.98fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@59.94fps, 3840x2160@23.98fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@29.97fps, 4096x2160@23.98fps, 4096x2160@24fps, 4096x2160@25fps

Weight and Dimensions

Depth	31.5 mm
Width	151 mm
Height	91.5 mm
Weight	196 g
