11
Step 2 (C1): Installation of hexagonal jaws
Hexagonal jaws
5.Installation guide
Note:
1. When tilting and engraving, use the motor rotation button to adjust the appropriate position for
engraving
Key points of operation: when engraving a cued suace, take the measured object Diameter/-
circumference average of actual engraving range (engraving The three values on the left, middle
and right of the range position are equal mean)
Suppo column assembly
