Atronic e-motion - Game Screen Layout

13
April 2008
e-motion™ Installation
e-motion™ Cabinet
Weight: approx. 120 Kg / 264 lbs.
Overall dimensions closed cabinet
Height: max. 1350 mm / 53.2"
Width: 610 mm / 24"
Depth: max. 590 mm / 23.2"
DIMENSIONS
adjustable1230mm- 1350mm/48.4”- 53.2”
1055mm/41.5”
1643mm/64.7”
575mm-590mm/22.6”-23.2” 550mm/21.7”
610mm/24”
~420mm- 540mm/16.5”- 21.3”
e-motion™ Cabinet
with Topper
Weight: approx. 129 Kg / 284 lbs.
Overall dimensions closed cabinet
Height: 1643 mm / 64.7"
Width: 610 mm / 24"
Depth: max. 590 mm / 23.2"
DIMENSIONS
adjustable 1230-1350
575-590
550
685(mm)
905 (575 )opened closed
610
1055
135
