e-motion™ Installation
BASIC SETUP
Atronic machines usually come configured as specified
during order processing. However it might be
necessary to reconfigure basic machine settings,
such as denomination, metering, paytable, etc. The-
se settings can not be altered during normal
operation, as they require a machine re-initialisation
for technical or jurisdictional reasons.
Note: Please refer to the document "Manual HI Soft-
ware (version)" relevant for a particular software
version (e.g. C5.1.x.x) for detailed information.
1.Configure the Commboard
This is necessary only, if you have to alter the comm-
board settings, such as progressive mode or chan-
nel allocation.
2.Carry out a RAM Reset (incl. Commboard Clear)
This will clear all machine data, statistics and set-
tings, including progressive jackpot configuration.
3.Carry out the Initial Setup
After a RAM Reset the machine automatically en-
ters the Initial Setup menu. The Initial Setup al-
lows to configure all basic machine setting.
4.Carry out (Progressive) Jackpot Configuration
A PC or notebook with Atronic's Alink Config soft-
ware is connected to the gaming machine and
uploads the progressive jackpot configuration data.
Important: It is necessary to carry out the pro-
gressive jackpot configuration directly after the
Initial Setup. Do not insert credits before the jack-
pot configuration data is uploaded.
In an Atronic Progressive Link™ (APL) the jackpot
configuration has to be carried out at the APL ma-
ster machine only. The jackpot configuration data is
then transferred to all linked APL slave machines.
5.Adjust game settings in the Service Menu
