e-motion™ Installation
TECHNICAL DATA
Electrical Specifications
Required Voltage: 100V to 240V AC
50Hz / 60Hz
The mains power cable must be pluged into a earthed
power outlet labled 8 Amps.
Power Consumption
Idle Mode: approx. 200W
1.8 A / 115V, 0.9 A / 230V
Payout Mode: approx. 300W
2.6 A / 115V, 1.3 A / 230V
Power Supply
Secondary Voltage: + 24V / 4A
+ 12V / 12A
- 12V / 0.3A
+ 5V / 11A
+ 3.3V / 7A
Fuses
Power Supply: T 8A / 250V
Filterboard F2: +12V T 6.3A / 250V (UL fuse)
Filterboard F3: +24V T 4A / 250V (UL fuse)
Lamps
Fluorescent Lamp TL8W/33
300mm, 410 lumen,
4100K (cool white)
Button Lighting LED 12V
Environmental specifications
Operating Temperature: 0°C - 45°C (32°F - 113°F)
Operating Humidity: 0% - 85% (non condensing)
(same limits for storage)
Primary Voltage
(The power supply features
voltage autoswitching)
Secondary Voltage
Primary Fuses
Secondary Fuse
Lamps
Suggested Limits
