Atronic e-motion - Info Screen and Upper Display

18
April 2008
e-motion™ Installation
50
117.5
307.5
50
105.5
270.5
394
491
41.5
181
6060
55
60
50
357.5
541
Baseplate(AIS)
Cabinet
Footprint
550
Ø10mm
Ø10mm
(drill1 outof3 forsecuringbolt)
Backside
DRILLING TEMPLATE
Make sure to leave min. 180mm (7.1") distance to the next machine or
a wall on both sides of the cabinet. Do not cover the ventilation slots
at the backside of the cabinet.
MACHINE INSTALLATION
