AUDAC AWP06 - Technical Specifications; Product Specifications Table

AWP06 - User manual010
Technical specications
RMS power 6 Watt
Max power 10 Watt
Impedance 8 Ohm
Sensitivity (1W / 1m) 91 dB
Sound pressure (Max W/1m) 95 dB
Frequency response (±3 dB) 100 Hz - 15 kHz
Driver 4”
IP Rating 65
Line Transformer Tappings 1 6 W / 1666 Ohm
2 3 W / 3333 Ohm
3 1.5 W / 6666 Ohm
Dimensions (Ø x D)
140 x 148.5 mm
Built-in depth 148.5 mm
Cut-out measurement
125 mm (Ø)
Weight 0.79 kg
Operating temperature -20°C ~ 60°C
Construction ABS
Colours White (RAL9010)
