Chapter 4
Additional information
Technical specifications
Inputs Mic in Type Balanced microphone
Connector 3-pin terminal block ~ 3.81 pitch
Sensitivity 0 dB ~ -50 dB
Other Phantom power (15V DC)
Priority
Line in Type Unbalanced stereo line
Connector RCA (2x)
Sensitivity +4 dB ~ -20 dB
Front line input Type Unbalanced stereo line
Combined with Line in (RCA)
Connector 3.5 mm stereo jack
Priority mute contact Type Priority mute
2-pin terminal block ~ 5.08 mm pitch
Outputs Volt / Imp 4 Ω COM104 12.65 V
COM108 17.89 V
100 V COM104 250 Ω
COM108 125 Ω
70 V COM104 125 Ω
COM108 62.5 Ω
Connector 4-pin terminal block ~ 5.08 mm pitch
Frequency response 20 Hz - 20 kHz
Signal to Noise ratio > 90 dB
Total Harmonic Distortion + Noise < 0.5%
Crosstalk > 70 dB
Controls Master volume control
Two band tone control (output)
Input volume control
Indicators Power
Protect
Clip
-20 dB
Signal
