Additional information CPR12
TECHNICAL SPECIFICATIONS
Chapter
4
Balanced Master Output 0dBm
Unbalanced Sub Output 0dBm
Rated Output Voltage
Unbalanced Rec output -10dBm
Balanced Microphone
channels
-60dBm
Balanced Line 1-6 channels -30dBm
Unbalanced Line 7-10
channels
-30dBm
Unbalanced Priority 0dBm
Input sensitivity for rated output
at maximum gain
Insert 0dBm
Mic in to Master Output
Line in to Master Output
Mic in to Sub Output
Total Harmonic Distortion
(T.H.D) at 1KHz Rated output
Mic in to Rec Output
Less than 0.2%
Frequency Response Rated Output 20Hz~20KHz ±3dB
HIGH (12.5KHz) ±12dB
MID(2.5KHz) ±12dB Input Channel EQ
LOW(80Hz) ±12dB
HIGH (12.5KHz) ±12dB
Output Channel EQ
LOW(80Hz) ±12dB
Residual Noise less than -90dB
Crosstalk At 1KHz less than -70dB
Phantom Power (balanced) +15V DC
Power Source
AC 100~120V / 50~60Hz AC
220~240V / 50~60Hz DC 24V
Power Consumption 22Watts
Weight 5.3 kg
General
Dimensions 482(W)x325(D)x88(H)
