front and rear panel of the CPR12
FRONT PANEL
1. Trim Controls
These controls allow variable input level. They have 44dB adjustable ranges - 60dB to -16dB
for microphone level and -30dB to +14dB for line level.
2. Signal Indicators
These indicators show the present input signal on each input channel.
3. Peak Indicators
These indicators warn against clipping shortly on each input channel. When the peak indicator
is flickering, you should adjust the Trim Controls to achieve the best result.
4. Input Channel Fader
These faders allow you to adjust the level for each input channel.
5. Input Channel EQ Controls
6 MIC input channels have 3 bands equalizers which are adjustable over a wide range.
1 2 3
4
5 6 7 9 11 13 15
1412108
