6. PFL Switches
This switch allows you to monitor the pre-fader signal of the input channel through the
monitor speaker.
7. Output Channel Selectors
These selectors allow each input signal to be routed to the selected output channel.
8. Output Channel EQ Controls
Output channels have 2 bands equalizers which are adjustable over a wide range.
9. Output Channel Fader
These faders allow level adjustment for main output channels.
10. Clip Indicators
These indicators warn against clipping shortly on each output channel. When the peak
indicator is flickering, you should adjust the Trim Controls to achieve the best result.
11. Output Level Meters
These indicators show the output signal level.
12. AFL Switches
This switch allows you to monitor the selected main output signal through to the output
channel through the monitor speaker.
13. Monitor Level Control
This control allows you adjust the signal level of the monitor speaker.
14. Power Indicator
This indicator shows the power on/off status.
15. Power Switch
The device will be supplied with power when this switch is pressed and locked.
