Step 3: Attach the speaker
After the wall support bar is attached and the connections are made, the soundbar shall
be fixed to the wall plate. This is done by sliding the hooks assembled to the soundbar
into the provided slots on the wall support bar and fixing them.
To prevent the soundbar from falling down, the security screw on top of the fixation
hooks shall be tightened.
NOTE
The wall bracket for the IMEO1 speakers is designed in such way that the speaker can
be hooked onto it in two directions. The normal direction (speakers facing upwards) is
used when the soundbar is positioned underneath the TV, display or projection surface.
The reversed direction (speakers facing downwards) is used when the soundbar is
positioned above it.
When mounted in reversed direction, the logo on the front grill can be rotated through
pulling it out of the recess and turning it.
