Front panel description
Unbalanced line input
An unbalanced stereo audio source can be connected to these RCA connectors.
Balanced microphone input
A balanced microphone can be connected to this XLR input connector. For powering condenser
microphones, 12V Phantom power can be enabled.
Push-Lock gain control potentiometer with clipping LED
The sensitivity for the line and microphone inputs can be adjusted with these potentiometers.
Through the push-lock mechanism, they can be opened and hidden again by pressing them.
Above every potentiometer is a clipping indicator LED provided which illuminates when clipping
of the input signal occurs. When this LED is lit, the signal is distorted and the level should be
reduced by turning back the potentiometer. The sensitivity for the line and microphone input can
be adjusted between the ranges of 0dB and -∞dB.
Master Volume Control
By means of this rotatable dial, the overall volume can be controlled. The volume can be
increased by turning the dial to the right, while it can be decreased by turning the dial to the left.
