Chapter 4
Technical Specifications
Line input Stereo, RCA input
Sensitivity: +12dB / -6dB
Signal / Noise: > 95 dB
THD+N: < 0.02
Microphone input Balanced, XLR input
Sensitivity: -20dB / -46dB
Signal / Noise: > 85 dB
THD+N: < 0.05
Phantom power 12V DC
Connector 8-pin Euro Terminal block
Dimensions 153 x 94 x 55 mm
Built-in Depth 37 mm
Weight 0.175 Kg
Installation standard BS4662 - 2 gang
