Chapter 3
Installing & Connecting
Installing
For installing the WP523, two different kinds of flush mount installation boxes are available.
The plastic installation box (WB5065/FG) is meant to be used for installation into gypsum, wooden
or other kinds of plate walls with a thickness between 7 mm and 25 mm. An installation hole with
dimensions 135 x 75 mm should be cut wherein the installation box should be placed. When the wall
panel is placed into the installation box and the screws are tightened, the wall panel will be secured to
the wall.
The second type of installation box is a steel version (WB5065/FS) which can be used for mortar in
brick or stone walls. Make sure the installation box is installed upright (notice the text and the sticker
on the installation box)
