Chapter 2
Quick start guide
This chapter guides you through the setup process for a basic setup where a WP523 should be
connected to a LX523 loudspeaker system.
Install your WP523 wall panel on the desired location by means of the optional available WB5065
installation boxes. Provide a twisted pair cable from the loudspeaker to the WP523 wall panel.
Connect the twisted pair cable according to the standards described in this user manual with the RJ45
connector on the loudspeaker side and to the 8-pin Euro-Terminal block connector on the wall panel
side. After all those connections are made, just plug-in the connectors of the twisted pair cable, plug
in the mains power on the loudspeaker side and your system is ready for operation.
You can plug in your line and microphone audio sources to the wall-panel, and your sounds should be
audible through the speaker system. The master volume and mixing can be done with the push-lock
and the big rotatable dial on the wall panel. Make sure that the settings for volume and tone control
on the rear side of the speaker system are correct too.
