Parking system plus with
rearview camera
Introduction
Applies to: vehicles with parking system plus with rear view
camera
. I
-
Fig. 129 Illust ratio n: Cross parking
Fig. 130 Illust rat ion: parallel park ing
Vehicles with the parking system plus are equip-
ped with a rear view camera in addition to the
acoust ic and visual parking system .
You can use
cross parking for example, to park in
a parking space or in a garage ¢
fig. 129. You can
use
parallel parking if you would like to park on
the side of the road
c:> fig . 130 .
Parking systems
General information
Applies to: vehicles with parking system plus with rear view
came ra
Fig. 131 Area covered (D and area not covered @ by the
rear view camera
rlFI)
AUlJ.a.
Fig. 132 Rear lid: Location of the rea r view camera
Sensors
Sensors are located in the front and rear bump-
ers. If these detect an obstacle, visual and in
some situations audible signals warn you .
CD
~
M
0
:i:
~
M
N
q
X
..,
m
Make sure the sensors are not covered by stick-
ers, deposits or any other obstructions as it may
impair the sensor function . For information on
cleaning, refer to ¢
page 206 .
The display field begins approximately at:
front
side
3 ft (0.90 m)
center 4 ft (1.20 m)
side
2 ft (0.60 m)
rear
center 5.2 ft (1.60 m)
The closer you get to the obstacle, the shorter
the interval between the audible signals. A con-
tinuous tone sounds when the obstacle is less
than approximately 1
ft (0.30 m) away. Do not
continue driving farther
c:> A in General informa-
tion on page 118,
~0 in General information on
pagellB!
liJ,
119
