Parking sy stem s
.,. Select the @ symbol with the control knob and
press the control knob.
You can choose between t hree different views in
this mode .
.,. To cross park, parallel park, or position the ve-
hicle in front of a trailer* , press the ® contro l
button on the unit repeatedly unti l the symbol
for the desired mode is selected.
Cross parking
Applies to: vehicles with to p view camera system
This view may be used when parking in a garage
or in a parking space.
Fig. 14 6 I nfota inme nt : aim ing at a par king space
Fig. 147 Infotainme nt : aligning th e vehicle
Requirement: cross parking is selected
c::>page 125 .
.,. The orange colored or ientat ion lines (!) show
the d irection of travel of the vehicle. Turn the
steering wheel until the orange orientation
lines appear in the parking space
c::>fig . 146 .
Use the mark ings @ to help you est imate the
distance from an obstacle . Each marking repre-
sents about 3
ft (1 m) . The blue area represents
an ext ension of the veh icle's outline by approx i-
ma t ely 16 ft (S m) to the rear.
126
.,. Wh ile driving in reverse gear, adjust the steer-
ing wheel angle to fit the parking space with
the aid of the orange orientat ion lines
c::> A in
General informa t ion on page 123 , c::>(D in Gen-
eral informa t ion on page 123 . @
marks the
rear bumper . Stop the vehicle when the red ori-
entation line @) borders an obstacle
c::> .&. in
General information on page 120 .
Parallel parking
Applies t o: vehicles with top view camera system
This view may be used when parallel parking
along the side of a street.
Fig. 14 8 Infota inment : blue surfaces aligned in the park-
ing space
Fig. 149 Infot ainm ent: contac t of t he blue curved line with
the curb
Parking on the right is described here . It is identi-
cal when parking on t he left .
If there is an obstacle next to the parki ng space
(such as a wall), refer to information for "Parking
next to obstacles "
c::> page 127.
.,. Activate the turn signal.
.,. Posit ion your veh icle next to a parked vehicle in
front of the des ired parking space . The distance
Iii>
