Audient ASP 008 User Manual

©audient 05/2008
Copyright 2003. All rights reserved.
The information in this document is subject to change without notice.
Audient plc makes no warranty of any kind with respect to the material in this document
and shall not be liable for errors contained herein or for incidental or consequential
damages related to the use of the material.
No part of this document may be reproduced without the prior written consent
of audient plc.

Audient ASP 008 Specifications

Audio Specifications

Maximum input level	+21.5 dBu
Maximum output level	+27.5 dBu
Total harmonic distortion	0.007% at 1kHz
Equivalent input noise	-127.5 dB @ 60dB gain/ref 150 ohms
Frequency response	-0.3 dB @10Hz to -3 dB @300kHz at unity gain
Common mode rejection ratio	75 dB at 1kHz and 60dB gain

Power

power consumption	40 watts

Weight and Dimensions

dimensions	480 mm x 278 mm x 44 mm
weight	4.5 kg
