Specifications†
Overall System
Operating Frequency UK - UHF band, 840.00 to 865.00 MHz
Spain - UHF band, 840.00 to 865.00 MHz
EX (Rest of Europe) - UHF band, 840.00 to 865.00 MHz
Number of Channels 10 total
Frequency Stability ±0.005%, Phase Lock Loop frequency
control
Modulation Mode FM
Normal Deviation ±5 kHz
Operating Range 300’ typical
Operating Temperature Range 41° F (5° C) to 113° F (45° C)
Frequency Response 100 Hz to 15 kHz
Receiver
Receiving System Dual independent receivers, automatic-
switching diversity
Image Rejection 55 dB nominal, 50 dB minimum
Signal-to-noise Ratio >100 dB at 40 kHz deviation
(A-weighted), maximum modulation
40 kHz
Total Harmonic Distortion <1% (±10 kHz deviation at 1 kHz)
Sensitivity 20 dBµV (S/N 60 dB at 5 kHz deviation,
IEC-weighted)
Intermediate Frequency 65.75 MHz, 10.7 MHz
Audio Output (AF Level set at “0”)
Unbalanced:
1
/
4
" phone jack
Balanced: XLRM-type
Unbalanced: 25 mV (at 1 kHz, ±5 kHz deviation,
100k ohm load)
Balanced: 12.5 mV (at 1 kHz, ±5 kHz deviation,
100k ohm load)
Antenna Inputs BNC-type, 50 ohms, "A" and "B"
Antenna Power +12 V DC in input jacks, 20mA max. from "A"
jack, 20mA max. from "B" jack.
Power Supply 230V AC 50 Hz, or 12-18V DC, 500 mA
,
with external supply
Dimensions 8.27" (210.0 mm) W x 1.73" (44.0 mm) H
x 6.39" (162.2 mm) D
Weight 2.2 lbs (1.0 kgs)
Accessories Included Two flexible UHF antennas, rack-mount adapters,
UK - Type BF : AD1210UK
Rest of Europe - Type C-4: AD1210E
UniPak
™
Transmitter
RF Power Output 10 mW
Spurious Emissions According to National Regulations
Input Connections High impedance, low impedance, bias
Batteries (not included) Two 1.5V AA alkaline
Current Consumption 150 mA typical
Battery Life Approximately 9 hours (depending on
battery type and use pattern)
Dimensions 2.60" (66.0 mm) W x 3.63" (92.3 mm) H
x 0.89" (22.5 mm) D
Net Weight (without batteries) 2.82 oz (80 g)
Handheld Transmitters
RF Power Output 10 mW
Spurious Emissions According to National Regulations
Microphone Element Dynamic, unidirectional
Batteries (not included) Two 1.5V AA alkaline
Current Consumption 150 mA typical
Battery Life Approximately 9 hours (depending
on battery type and use pattern)
Dimensions9.02" (229.0 mm) long x 2.11" (53.5 mm)
maximum diameter
Net Weight (without batteries) 7.81 oz (221.5 g)
Accessory Included AT8456a Quiet-Flex
™
stand clamp
†
Specifications are subject to change without notice.
