15
Specifications
Turntable specifications
Type 3-speed, fully manual operation
Motor DC servo motor
Drive method Direct drive
Speeds 33-1/3 RPM, 45 RPM, 78 RPM
Turntable platter Die-cast aluminum
Starting Torque > 1.0 kgf.cm
Braking System Electronic brake
Wow and flutter < 0.2% WRMS (33 RPM) at 3 kHz
Signal-to-noise ratio > 50 dB
Output levels
“PHONO”
“LINE (MM)”
4 mV nominal at 1 kHz, 5 cm/sec
240 mV nominal at 1 kHz, 5 cm/sec
Phono Pre-amp gain 36 dB nominal, RIAA equalized
Tonearm specifications
Type Static balanced S-shaped tonearm
Effective length 230.5 mm
Overhang 16 mm
Maximum tracking error angle Less than 3°
Stylus pressure adjustment
range
0 to 4 g
Applicable cartridge weight
range
3.5 to 8.5 g
Cartridge and headshell specifications
Cartridge Model AT-VM95E
Cartridge Type VM
Recommended load
impedance
47,000 ohms
Output voltage 4.0 mV (1 kHz, 5 cm/sec)
Stylus 0.3 × 0.7 mil bonded elliptical stylus
Cantilever Aluminum pipe
Tracking force range 1.8 to 2.2 g (2.0 g standard)
Cartridge weight 6.1 g (0.22 oz)
Headshell model AT-HS6
Headshell weight 9 g (0.32 oz) (including lead wire)
Headshell overhang
adjustment
± 5 mm
USB function
A/D, D/A 16 bit 44.1 kHz or 48 kHz USB
selectable
Computer interface USB 1.1 Compliant Windows 7 or
above, or MAC OSX or above
General specifications
Power supply requirements 100 to 240 V, 50/60 Hz, 1.5 A Max.
Power consumption 2.8 W
AC Adapter 12 V, 3 A
Dimensions 452.0 mm (17.80") × 352.0 mm
(13.86") × 141.6 mm (5.57")
(W × D × H)
Weight 8 kg (17.6 lbs) (without dust cover)
Accessories Dust cover, Felt mat, Platter,
Counterweight, Headshell (AT-HS6)
with VM stereo cartridge (AT-VM95E),
45-RPM adapter, Stylus target light,
Dust cover hinges, USB cable (1.9m
(6.2')), RCA audio cable (approx.
1.4m (4.6')), AC adapter (approx.
1.3m (4.3') (AD-SA1230WD)
Replacement stylus (sold
separately)
AT-VMN95E
Replacement headshell (sold
separately)
AT-HS6
Specifications are subject to change without notice due to
improvements.
