Audio Technica AT2020USB-XP User Manual

52
Connecting and using the headphones
You can monitor sounds being recorded by connecting headphones to the headphone jack. Also, you can directly
monitor your own voice from the product while listening to a sound source from your computer.
1
Connect the headphones to the headphone jack.
2
Turn the headphone level control dial to adjust the volume.
Note
• The headphone level control dial adjusts the volume of the headphone output; it does not adjust the
microphone level.
Using the mix control dial
The product allows you to directly monitor your own voice from the product while listening to a sound source from your
computer. You can use the mix control dial to adjust the balance of the volume level of the sound source stored on the
computer and the monitored volume level of the audio being input.
➊ Turning the dial toward the microphone side increases the monitored volume level of the audio being input.
➋ Turning the dial toward the computer side increases the volume level of the sound source stored on the computer.

Audio Technica AT2020USB-XP Specifications

General

Headphone out	Yes
Device interface	3.5 mm (1/8\
USB connector type	USB Type-C
Connectivity technology	Wired
Type	PC microphone
Bit rate	24 bit
Sample rate	192 kHz
Volume control	Rotary
Microphone frequency	20 - 20000 Hz
Microphone Total Harmonic Distortion (THD)	1 %
Output impedance	32 Ω
Cable length	2 m
Control type	Buttons, Rotary
Product color	Black
Windows operating systems supported	Windows 10, Windows 11
Cables included	USB Type-C to USB Type-A
Number of products included	1 pc(s)
Power source	USB
Input voltage	5 V

Weight and Dimensions

Height	142 mm
Diameter	52 mm
Microphone weight	375 g
