Audio Technica AT2020USB-XP User Manual

61
Specifications
System requirements
USB 2.0 compliant
Supported OS Windows 10, Windows 11
macOS Catalina, macOS Big Sur, macOS Monterey, macOS Ventura
(Please check the product's web page for the latest information.)
Element Fixed-charge back plate, permanently polarized condenser
Polar pattern
Cardioid
Frequency response
20-20,000 Hz
Power supply USB power (5 VDC)
Bit depth 16 bit/24 bit
Supported sampling rates
44.1 kHz/48 kHz/88.2 kHz/96 kHz/192kHz
[1]
Controls Headphone level control, Mix control, Mute, Auto gain control, Noise-
reduction
Dimensions 142 mm (5.6") long, 52 mm (2.0") maximum body diameter
Weight
About 375 g (13 oz)
Output connector
USB Typ e-C
Headphone output 110 mW (at 1 kHz, 1% T.H.D., 32 ohms)
Headphone jack
3.5 mm (1/8") stereo mini-jack
Included accessories Stand (AT8702), Pop filter (AT8175 / AT8155
[2]
), 3/8"-16 to 5/8"-27 threaded
adapter, USB cable (about 2.0 m (6.6'), USB Type-C to USB Type-A), USB
conversion adapter (USB Type-A to USB Type-C)
[1] Playback at 24-bit and 192 kHz is not supported.
[2] Available only in the United States.
• For product improvement, the product is subject to modification without notice.

Audio Technica AT2020USB-XP Specifications

General

Headphone out	Yes
Device interface	3.5 mm (1/8\
USB connector type	USB Type-C
Connectivity technology	Wired
Type	PC microphone
Bit rate	24 bit
Sample rate	192 kHz
Volume control	Rotary
Microphone frequency	20 - 20000 Hz
Microphone Total Harmonic Distortion (THD)	1 %
Output impedance	32 Ω
Cable length	2 m
Control type	Buttons, Rotary
Product color	Black
Windows operating systems supported	Windows 10, Windows 11
Cables included	USB Type-C to USB Type-A
Number of products included	1 pc(s)
Power source	USB
Input voltage	5 V

Weight and Dimensions

Height	142 mm
Diameter	52 mm
Microphone weight	375 g
