Audio Technica AT2040USB User Manual

50
Connecting and using the headphones
You can monitor sounds being recorded by connecting headphones to the headphone jack. Also, you can directly
monitor your own voice from the product while listening to a sound source from your computer.
1
Connect the headphones to the headphone jack.
2
Turn the headphone level control dial to adjust the volume.
Note
• The headphone level control dial adjusts the volume of the headphone output; it does not adjust the
microphone input level.
Using the mix control dial
The product allows you to directly monitor your own voice from the product while listening to a sound source from your
computer. You can use the mix control dial to adjust the balance of the volume level of the sound source stored on the
computer and the monitored volume level of the audio being input.
➊ Turning the dial toward the microphone side increases the monitored volume level of the audio being input.
➋ Turning the dial toward the computer side increases the volume level of the sound source stored on the computer.

Audio Technica AT2040USB Specifications

General

Type	PC microphone
Bit rate	24 bit
Sample rate	96 kHz
Microphone mute	Yes
Microphone frequency	80 - 16000 Hz
Microphone Total Harmonic Distortion (THD)	1 %
Device interface	3.5 mm (1/8\
USB connector type	USB Type-C
Connectivity technology	Wired
Cables included	USB Type-C to USB Type-A
Number of products included	1 pc(s)
Cable length	2 m
Product color	Black
Windows operating systems supported	Windows 10, Windows 11
Power source	USB
Input voltage	5 V
Output impedance	32 Ω

Weight and Dimensions

Height	145.3 mm
Diameter	52 mm
Microphone weight	600 g
