Audio Technica ATH-CKS50TW User Manual

18
Connecting via Bluetooth
To connect the product to a Bluetooth device, the product needs to pair (register) with the device.
Pairing a Bluetooth device
Read the user manual for the Bluetooth device.
Place the Bluetooth device within 1 m (3.3') of the product to perform pairing correctly.
Wear the product to hear voice guidance during pairing.
1
Remove the headphones (L (left) and R (right)) from the charging case.
The indicator lamps will light in white, and then flash.
2
Use your Bluetooth device to begin the pairing process and search for the product. When your
Bluetooth device finds the product, “ATH-CKS50TW” will be displayed on the device.
For information about using your Bluetooth device, refer to the device’s user manual.
3
Select “ATH-CKS50TW” to pair the product and your Bluetooth device.
Some devices may ask for a passkey. In this case, enter “0000”. The passkey may also be called a passcode,
PIN code, PIN number, or password.

Audio Technica ATH-CKS50TW Specifications

General

Headset type	Binaural
Product type	Headset
Product color	Black
Wearing style	In-ear
Recommended usage	Calls/Music
Impedance	16 Ω
Driver type	Dynamic
Driver unit	10 mm
Ear coupling	-
Headphone frequency	5 - 40000 Hz
Maximum input power	10 mW
Headphone sensitivity	110 dB
Battery type	Built-in battery
Battery voltage	3.7 V
Charging source	USB
Battery operated	Yes
Battery recharge time	2 h
Continuous audio playback time	15 h
Battery recharge time (charging case)	3.5 h
Operating temperature (T-T)	5 - 40 °C
Microphone type	Built-in
Microphone frequency	50 - 4000 Hz
Microphone sensitivity	-40 dB
Microphone direction type	Omnidirectional
Cables included	USB Type-A to USB Type-C
Frequency band	2.402 - 2.480 GHz
Bluetooth version	5.0
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
Connectivity technology	True Wireless Stereo (TWS)

Weight and Dimensions

Charging case weight	60 g
Left earpiece weight	8 g
