Audio Technica ATH-SR50BT User Manual

19
Headphones
Type
Dynamic
Driver
40 mm
Sensitivity 103 dB/mW (when using noise-cancelling function)*
1
100 dB/mW (when not using noise-cancelling function)*
1
Frequency response
5 to 45,000 Hz
Impedance
35 ohms (unit impedance)*
1
Microphone
Type
Electret condenser
Polar pattern
Omnidirectional
Sensitivity
-44 dB (1 V/Pa, at 1 kHz)
Frequency response
50 to 4,000Hz
Communication specifications
Communication system
Bluetooth version 5.0
RF output
Less than 10 mW EIRP
Maximum communication range
Line of sight - approx. 10 m (33')
Frequency band
2.402 GHz to 2.480 GHz
Modulation method
FHSS
Compatible Bluetooth profiles
A2DP, AVRCP, HFP, HSP
Support codec
Qualcomm
®
aptX™ audio, AAC, SBC
Supported content protection method
SCMS-T
Transmission band
20 to 20,000 Hz
*
1
During wired connection.
Specifications

Audio Technica ATH-SR50BT Specifications

General

Impedance	47 Ω
Driver type	Dynamic
Driver unit	45 mm
Ear coupling	Circumaural
Headphone frequency	5 - 40000 Hz
Microphone type	Built-in
Microphone frequency	50 - 4000 Hz
Microphone sensitivity	-44 dB
Microphone direction type	Omnidirectional
Cables included	USB
Battery type	Built-in battery
Battery voltage	3.7 V
Battery recharge time	5.5 h
Continuous audio playback time	28 h
Cable length	0.3 m
Headset type	Binaural
Product type	Headset
Product color	Gray
Wearing style	Head-band
Volume control	Touch
Recommended usage	Calls/Music
Operating temperature (T-T)	5 - 40 °C
USB connector	Micro-USB
Frequency band	2.402 - 2.48 GHz
Wireless range	10 m
6.35 mm connector	No
Bluetooth version	5.0
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
Connectivity technology	Wireless
Package depth	225 mm
Package width	252 mm
Package weight	700 g

Weight and Dimensions

Weight	262 g
