Audio Technica ATR2500x-USB User Manual

16
Element: Condenser
Polar Pattern: Cardioid
Frequency Response: 30 – 15,000 Hz
Power Requirements: USB Power (5V DC)
Bit Depth: Up to 24 bit
Sample Rate: 44.1 kHz/48 kHz/96 kHz/192 kHz
Controls: Headphone volume (up/down) buttons
Weight: 366 g (12.9 oz)
Dimensions: 155.0 mm (6.10") long, 50.0 mm (1.97") maximum body diameter
Output Connector: USB-C
Headphone Output Power: 10 mW @ 16 ohms
Headphone Jack: 3.5 mm (
1
/
8
") TRS (stereo)
Accessories Furnished: Pivoting stand mount for ⅝"-27 threaded stands, tripod desk stand, 2 m (6.6') USB-C to USB-C
cable (USB On-The-Go Compliant), 2 m (6.6') USB-C to USB-A cable
System Requirements: Macintosh: Mac OS X; USB 1.0 or 2.0; 64 MB RAM (minimum);
Windows: Windows 7/8/10; USB 1.0 or 2.0; 64 MB RAM (minimum)
†In the interest of standards development, A.T.U.S. offers full details on its test methods to other industry professionals on request.
Specifications are subject to change without notice.
LEGEND
200 Hz
1 kHz
5 kHz
8 kHz
SCALE IS 5 DECIBELS PER DIVISION
240˚
180˚
210˚
270˚
300˚
330˚
0˚
150˚
120˚
90˚
30˚
60˚
12" or more on axis
LEGEN
D
Frequency in Hertz
Response in dB
10 dB
100
50
200
10k
5k
1k
500
2k
20k
LEGEND
200 Hz
1 kHz
5 kHz
8 kHz
SCALE IS 5 DECIBELS PER DIVISION
240˚
180˚
210˚
270˚
300˚
330˚
0˚
150˚
120˚
90˚
30˚
60˚
12" or more on axis
LEGEND
Frequency in Hertz
Response in dB
10 dB
100
50
200
10k
5k
1k
500
2k
20k
Frequency Response
Polar Pattern
ATR2500x-USB Specifications
†

Audio Technica ATR2500x-USB Specifications

General

Type	PC microphone
Bit rate	24 bit
Sample rate	192 kHz
Volume control	Buttons
Microphone frequency	30 - 15000 Hz
Desktop stand	Yes
Cables included	USB Type-C to USB Type-A, USB Type-C to USB Type-C
Number of products included	1 pc(s)
Power source	USB
Product color	Black
Compatible operating systems	Windows, Mac
Connectivity technology	Wired
Package depth	170 mm
Package height	250 mm
Package weight	605 g

Weight and Dimensions

Height	155 mm
Diameter	50 mm
Microphone weight	366 g
