Controls and Functions
“- --~X.“...X-.--.-.X--.“.-.~II....- “._ - .I .x- --.. -
0
;;g;g i
PROT
ymg :
PWR PROT
0
A2801Q :
PWR
A3201 Q :
00
yw;QQ :
A1801Q :
A66OlQ ;
‘..............-....--------------------~------~-----------.----~--.--~--------.
-PWR (Power) : This BLUE LED will illuminate when the amplifier is turned “ON”. If it fails to
illuminate, check the power connections to the Amplifier and fuses.
-PROT ( Protection] : The amplifier protection circuitry will disable the amplifier if input
overload, short circuit or extremely high temperature conditions are detected. When the
protection mode is in operation, the LED indicator on the side panel will be illuminated,
indicating the amplifier has gone into a self-preservation mode.
If you observe that the Protection LED is lit, please check the system carefully to determine
what has caused the protection circuit to engage. The amplifier can be reset by turning
the remote power off and then on again. If the amplifier shut down due to a thermal
overload condition, please allow it to cool down before restarting. If the amplifier shut
down because of an input overload or short circuit, be sure to repair these conditions
before attempting to power up the amplifier again,
A1801Q i
_________________________________
J
to change the phase of your
nsate fer timing differences between
