AudioCodes 405 Quick Guide

4. Mounting
You can mount your phone on a desktop or on a wall.
 Desktop mounting: Slide the short edges of the L-shaped stand (the prongs) into the phone's two rear
slots (see A below). Slide the prongs in until they lock.
 Wall mounting: Hook the phone's two rear notches (see B below) onto wall mounting screws.
Pull out the handset's cradle clip, which is by default in desktop mounting position, invert it, and then
push it back in. This is the wall mounting position.
5. Signing in to Lync
 To sign in with Skype for Business client, see the 405 User's Manual.
 To sign in with your phone number and PIN:
1. Press the Sign in softkey (when the LCD is in idle mode).
2. Enter your phone number and PIN (default sign-in method), and
press Sign in.
 To sign in with your username and password:
1. Press the Sign in softkey (when the LCD is in idle mode) and scroll down to
select Switch sign-in method.
2. Enter your sign-in address (SIP address). Press the phone's 1 key to enter a period/fullstop. To enter
@ or -, repeat-press it until @ or - is displayed. Press Clear to edit. Press the control to scroll across.
3. Scroll down and enter your domain\username, e.g., company\mike. Repeat-pres s the phone's # key
to select abc, ABC, Abc, or 123. Repeat-press the phone's 1 key until \.
4. Scroll down and enter your user password – the same you use for PC access - and then press Sign in.
 To sign out: Press the Status softkey when the LCD is in idle mode, and then press Sign out.
A
A
B
B
A
A

AudioCodes 405 Specifications

General

Backlight display	Yes
Display resolution	132 x 64 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Security algorithms	HTTPS, SRTP, SSL/TLS
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	IPv4, TCP, UDP, ICMP, ARP, RTP, SRTP, RTCP-XR, 802.1x, IP/DHCP IP, IEEE 802.1p/Q, QoS/ToS, HTTP/HTTPS/DHCP, NTP, FTP/TFTP, CDP/LLDP VLAN, LDAP
Voice codecs	G.711Mu, G.711a, G.722, G.729A, G.729B
Lines quantity	2 lines
Phonebook capacity	- entries
Number of VoIP accounts	-
Volume control	Buttons
Number of programmable keys	4
AC adapter input voltage	100 - 240 V
Ethernet LAN (RJ-45) ports	2
Certification	FCC 15 B, ICES-003 B, EN55032 B, EN61000-3-2, EN61000-3-3, UL-60950-1, EN60950-1, IEC-60950-1 (CB), CE, cTUVus RCM, KC, Anatel, CCC, ICASA, EAC, IC, ACTA, VCCI, BSMI
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Dual-Tone Multi-Frequency (DTMF) modes	SIP info

Weight and Dimensions

Depth	180 mm
Width	191 mm
Height	153 mm
Weight	680 g
Package depth	200 mm
Package width	210 mm
Package height	100 mm
Package weight	900 g
